pygmt.config
- class pygmt.config(*, COLOR_BACKGROUND=None, COLOR_FOREGROUND=None, COLOR_CPT=None, COLOR_NAN=None, COLOR_MODEL=None, COLOR_HSV_MIN_S=None, COLOR_HSV_MAX_S=None, COLOR_HSV_MIN_V=None, COLOR_HSV_MAX_V=None, COLOR_SET=None, DIR_CACHE=None, DIR_DATA=None, DIR_DCW=None, DIR_GSHHG=None, FONT_ANNOT_PRIMARY=None, FONT_ANNOT_SECONDARY=None, FONT_HEADING=None, FONT_LABEL=None, FONT_LOGO=None, FONT_SUBTITLE=None, FONT_TAG=None, FONT_TITLE=None, FORMAT_CLOCK_IN=None, FORMAT_CLOCK_OUT=None, FORMAT_CLOCK_MAP=None, FORMAT_DATE_IN=None, FORMAT_DATE_OUT=None, FORMAT_DATE_MAP=None, FORMAT_GEO_OUT=None, FORMAT_GEO_MAP=None, FORMAT_FLOAT_OUT=None, FORMAT_FLOAT_MAP=None, FORMAT_TIME_PRIMARY_MAP=None, FORMAT_TIME_SECONDARY_MAP=None, FORMAT_TIME_STAMP=None, GMT_DATA_SERVER=None, GMT_DATA_SERVER_LIMIT=None, GMT_DATA_UPDATE_INTERVAL=None, GMT_COMPATIBILITY=None, GMT_CUSTOM_LIBS=None, GMT_EXPORT_TYPE=None, GMT_EXTRAPOLATE_VAL=None, GMT_FFT=None, GMT_GRAPHICS_DPU=None, GMT_GRAPHICS_FORMAT=None, GMT_HISTORY=None, GMT_INTERPOLANT=None, GMT_LANGUAGE=None, GMT_MAX_CORES=None, GMT_THEME=None, GMT_TRIANGULATE=None, GMT_VERBOSE=None, IO_COL_SEPARATOR=None, IO_FIRST_HEADER=None, IO_GRIDFILE_FORMAT=None, IO_GRIDFILE_SHORTHAND=None, IO_HEADER=None, IO_HEADER_MARKER=None, IO_N_HEADER_RECS=None, IO_NAN_RECORDS=None, IO_NC4_CHUNK_SIZE=None, IO_NC4_DEFLATION_LEVEL=None, IO_LONLAT_TOGGLE=None, IO_SEGMENT_BINARY=None, IO_SEGMENT_MARKER=None, MAP_ANNOT_MIN_ANGLE=None, MAP_ANNOT_MIN_SPACING=None, MAP_ANNOT_OBLIQUE=None, MAP_ANNOT_OFFSET_PRIMARY=None, MAP_ANNOT_OFFSET_SECONDARY=None, MAP_ANNOT_ORTHO=None, MAP_DEFAULT_PEN=None, MAP_DEGREE_SYMBOL=None, MAP_EMBELLISHMENT_MODE=None, MAP_FRAME_AXES=None, MAP_FRAME_PEN=None, MAP_FRAME_PERCENT=None, MAP_FRAME_TYPE=None, MAP_FRAME_WIDTH=None, MAP_GRID_CROSS_SIZE_PRIMARY=None, MAP_GRID_CROSS_SIZE_SECONDARY=None, MAP_GRID_PEN_PRIMARY=None, MAP_GRID_PEN_SECONDARY=None, MAP_HEADING_OFFSET=None, MAP_LABEL_MODE=None, MAP_LABEL_OFFSET=None, MAP_LINE_STEP=None, MAP_LOGO=None, MAP_LOGO_POS=None, MAP_ORIGIN_X=None, MAP_ORIGIN_Y=None, MAP_POLAR_CAP=None, MAP_SCALE_HEIGHT=None, MAP_TICK_LENGTH_PRIMARY=None, MAP_TICK_LENGTH_SECONDARY=None, MAP_TICK_PEN_PRIMARY=None, MAP_TICK_PEN_SECONDARY=None, MAP_TITLE_OFFSET=None, MAP_VECTOR_SHAPE=None, PROJ_AUX_LATITUDE=None, PROJ_DATUM=None, PROJ_ELLIPSOID=None, PROJ_GEODESIC=None, PROJ_LENGTH_UNIT=None, PROJ_MEAN_RADIUS=None, PROJ_SCALE_FACTOR=None, PS_CHAR_ENCODING=None, PS_COLOR_MODEL=None, PS_COMMENTS=None, PS_IMAGE_COMPRESS=None, PS_LINE_CAP=None, PS_LINE_JOIN=None, PS_MITER_LIMIT=None, PS_MEDIA=None, PS_PAGE_COLOR=None, PS_PAGE_ORIENTATION=None, PS_SCALE_X=None, PS_SCALE_Y=None, PS_TRANSPARENCY=None, TIME_EPOCH=None, TIME_IS_INTERVAL=None, TIME_INTERVAL_FRACTION=None, TIME_LEAP_SECONDS=None, TIME_REPORT=None, TIME_UNIT=None, TIME_WEEK_START=None, TIME_Y2K_OFFSET_YEAR=None, FONT=None, FONT_ANNOT=None, FORMAT_TIME_MAP=None, MAP_ANNOT_OFFSET=None, MAP_GRID_CROSS_SIZE=None, MAP_GRID_PEN=None, MAP_TICK_LENGTH=None, MAP_TICK_PEN=None)[source]
Change GMT default settings globally or locally.
Change GMT default settings globally:
pygmt.config(PARAMETER=value)
Change GMT default settings locally by using it as a context manager:
with pygmt.config(PARAMETER=value): ...
Full GMT defaults list at https://docs.generic-mapping-tools.org/6.6/gmt.conf.html.
Note
For GMT defaults to adjust the figure appearance, e.g., the font size,
pygmt.configneeds to be called after setting up thepygmt.Figureinstance to have an effect. This is relevant for both, global and local changes. For details see the GitHub issue comment.Note
PS_CONVERT is not supported. To configure conversion options, please pass parameters to
pygmt.Figure.savefigorpygmt.Figure.showinstead.
Examples using pygmt.config
Calculating grid gradient with custom azimuth and normalization parameters
